How to Configure DKIM, SPF, and DMARC for PowerMTA

You've installed PowerMTA and sent a test email. But it landed in spam. Sound familiar? Nine times out of ten, the problem is missing or broken email authentication. DKIM, SPF, and DMARC are the three pillars of email authentication, and without them, your emails are going to have a hard time reaching the inbox.

Let's fix that. This guide walks you through setting up all three for PowerMTA.

Why Email Authentication Matters

Email providers like Gmail, Yahoo, and Outlook use authentication to decide whether to trust your emails. Here's what each protocol does:

• SPF (Sender Policy Framework) — tells the world which IP addresses are allowed to send email on behalf of your domain
• DKIM (DomainKeys Identified Mail) — adds a cryptographic signature to each email, proving it wasn't altered in transit
• DMARC (Domain-based Message Authentication, Reporting & Conformance) — tells receiving servers what to do when SPF or DKIM checks fail

Without these, your emails look suspicious to receiving servers. With them, you're telling the world "yes, this email really came from us, and it hasn't been tampered with."

Setting Up SPF

What You Need

You need access to your domain's DNS settings. This is usually through your domain registrar (Namecheap, GoDaddy, Cloudflare, etc.).

Create the SPF Record

Add a TXT record to your domain's DNS:

Type: TXT
Host: @
Value: v=spf1 ip4:YOUR_SERVER_IP -all

Replace YOUR_SERVER_IP with your actual server IP address. If you have multiple IPs, list them all:

v=spf1 ip4:1.2.3.4 ip4:5.6.7.8 ip4:9.10.11.0/24 -all

The -all at the end means "reject emails from any IP not listed here." You can use ~all (soft fail) during testing, but switch to -all for production.

Verify Your SPF Record

dig TXT yourdomain.com

You should see your SPF record in the output.

Setting Up DKIM

Step 1: Generate DKIM Keys

PowerMTA can generate DKIM keys for you. Run this on your server:

sudo mkdir -p /etc/pmta/dkim
cd /etc/pmta/dkim
sudo openssl genrsa -out yourdomain.com.pem 2048
sudo openssl rsa -in yourdomain.com.pem -pubout -out yourdomain.com.pub

This creates a 2048-bit RSA key pair. The .pem file is your private key (stays on the server), and the .pub file contains the public key (goes in DNS).

Step 2: Add DKIM to PowerMTA Config

Edit /etc/pmta/config and add:

<domain yourdomain.com>
  use-starttls yes
  dkim-sign yes
  dkim-identity @yourdomain.com
  dkim-selector pmta
  dkim-key /etc/pmta/dkim/yourdomain.com.pem
</domain>

The dkim-selector can be anything you want. Common choices are pmta, mail, default, or s1.

Step 3: Add the DNS Record

Get your public key content:

cat /etc/pmta/dkim/yourdomain.com.pub

Copy everything between -----BEGIN PUBLIC KEY----- and -----END PUBLIC KEY-----, remove the line breaks to make it one long string, then create a DNS TXT record:

Type: TXT
Host: pmta._domainkey
Value: v=DKIM1; k=rsa; p=YOUR_PUBLIC_KEY_HERE

Replace pmta with whatever selector you chose in the config.

Step 4: Restart PowerMTA

sudo pmta reload

Step 5: Verify DKIM

dig TXT pmta._domainkey.yourdomain.com

You should see your DKIM public key in the response.

Setting Up DMARC

DMARC builds on top of SPF and DKIM. It tells receiving servers what to do when authentication fails and where to send reports.

Create the DMARC Record

Add a TXT record to your DNS:

Type: TXT
Host: _dmarc
Value: v=DMARC1; p=none; rua=mailto:dmarc-reports@yourdomain.com; pct=100

Here's what each part means:

• p=none — don't take action on failed emails (monitoring mode). Change to p=quarantine or p=reject once you're confident everything works.
• rua=mailto:... — where to send aggregate reports. These reports show you who's sending email using your domain.
• pct=100 — apply the policy to 100% of emails.

Recommended DMARC Rollout

1. Week 1-2: p=none — monitor only, collect reports
2. Week 3-4: p=quarantine; pct=25 — quarantine 25% of failing emails
3. Week 5-6: p=quarantine; pct=100 — quarantine all failing emails
4. Week 7+: p=reject — reject all failing emails

Don't jump straight to p=reject. If something is misconfigured, you could block your own legitimate emails.

Testing Everything Together

After setting up all three, send a test email to a Gmail address and check the headers. Look for:

Authentication-Results:
  spf=pass
  dkim=pass
  dmarc=pass

In Gmail, click the three dots on the email and select "Show original" to see the full headers.

You can also use online tools like mail-tester.com to get a detailed score of your email authentication setup.

Common Mistakes to Avoid

• Multiple SPF records: You can only have ONE SPF TXT record per domain. If you have multiple, merge them into one.
• Wrong DKIM selector: The selector in your DNS must match the selector in your PowerMTA config exactly.
• DKIM key too short: Use 2048-bit keys. Some older guides suggest 1024-bit, but that's no longer considered secure.
• Forgetting to reload: After changing the PowerMTA config, always run sudo pmta reload.
• DNS propagation: DNS changes can take up to 48 hours to propagate. Be patient.
